Adding a connection between two Microsoft Azure locations

Here’s an example below with a Cisco router.

You’ll assign the outer tag in NaaS Manager and the inner tag in the Azure portal (peering VLAN).

‘Primary EVC VLAN – 100 - NaaS Manager
‘Secondary EVC VLAN – 200 - NaaS Manager
‘Private Peering – VLAN 300 - Azure portal
‘MSFT Peering – VLAN 400 - Azure portal


interface GigabitEthernet0/1.100300

  encapsulation dot1Q 100 second-dot1q 300 ‘Azure Private primary peer
  description "Cloud Connect"
  ip address xxx.xxx.xxx.xxx 255.255.255.252


interface GigabitEthernet0/1.200300

  encapsulation dot1Q 200 second-dot1q 300
‘Azure Private secondary peer
  description "Cloud Connect"
  ip address xxx.xxx.xxx.xxx 255.255.255.252


interface GigabitEthernet0/1.100400
  encapsulation dot1Q 100 second-dot1q 400
‘MSFT primary peer
  description "Cloud Connect"
  ip address xxx.xxx.xxx.xxx 255.255.255.252


interface GigabitEthernet0/1.200400
  encapsulation dot1Q 200 second-dot1q 400
‘MSFT secondary peer
  description "Cloud Connect"
  ip address xxx.xxx.xxx.xxx 255.255.255.252

To add a connection between two Microsoft Azure locations:

  1. Click Services.

    Control Center shows the Services console. Use the console to access an inventory of your services, check the status of orders, and manage your services.
Services console
NaaS Manager Overview tab
